Schneider Servo Drive LXM32MU90M2
The Schneider Electric LXM32MU90M2 is a modular AC servo drive from the Lexium 32 series. The meaning this specific drive does not have a built-in fieldbus (like CANopen or EtherNet/IP) on the for optional communication and I/O modules.
Technical Specifications:
|
Feature |
Specification |
|
Product Series |
Lexium 32 Modular |
|
Phase / Voltage |
Single-phase (115V to 230 VAC) |
|
Nominal Current |
9A |
|
Peak Current |
28.2A, 2Sec |
|
Continuous Power |
1.6 kW at 230kW |
|
Integrated Safety |
STO (Safe Torque Off) SIL3/PLe |
|
EMC Filter |
Integrated (Class A) |
|
Feedback Supported |
SinCos Hiperface, EnDat 2.2 |
The Modular Concept (LXM32M)
Used for fieldbus modules like EtherNet/IP & Modbus TCP (VW3M3308), CANopen (VW3M3302), PROFINET (VW3M3309), or EtherCAT (VW3M3301). Allows for additional digital/analog inputs and outputs if the base I/O is insufficient.
