KEYENCE Fiber Sensor LR-WF10C
The KEYENCE LR-WF10C is a high-performance fiber-optic amplifier from the LR-W Series. This makes it exceptionally reliable for detecting subtle color differences or targets that are tilted, glossy, or dark.
Technical Specifications
| Feature | Specification |
| Light Source | White LED (Full-spectrum) |
| Response Time | 500ms (Selectable) |
| Control Output | PNP / NPN Selectable (Open collector) |
| Communication | IO-Link (v1.1 / COM2 supported) |
| Power Supply | 10-30VDC |
| Operating Temp | -20 to +45C (No freezing) |
| Enclosure Rating | IP65 (Dust and water-jet resistant) |
M12 4-Pin Connector Pinout
The LR-WF10C uses a standard M12 4-pin male connector. The function of the pins can change depending on whether you are using it in standard I/O mode or IO-Link mode.
| Pin No. | Wire Color | Signal Name | Description |
| 1 | Brown | L+ | Power Supply (10-30V DC) |
| 2 | White | Ext. Input | External Tuning / Transmission OFF (Selectable) |
| 3 | Blue | L- | Ground |
| 4 | Black | Output / C/Q | Control Output / IO-Link Communication |
