Siemens vfd G120 Series 30KW/37KW Inverter Power Module PM240 6SL3224-0BE33-0UA0

Description

Siemens VFD G120 Inverter Power Module PM240

Siemens VFD G120 Inverter Power Module PM240  is a range of versatile frequency inverters VFD designed for controlling the speed of electric motors.The PM240 Power Module 6SL3224-0BE33-0UA0 is a key component of the G120 series.

Key Features and Technical Specifications:

• Power Ratings:
  • High Overload: 30 kW (40 HP) at 200% for 3 seconds, 150% for 57 seconds, and 100% for 240 seconds.
  • Low Overload: 37 kW (50 HP) at 150% for 3 seconds, 110% for 57 seconds, and 100% for 240 seconds.
• Input:3-phase 380-480V, 47-63Hz, with a tolerance of +/- 10% and +/- 10% respectively.
• Integrated Braking Chopper: Enables the use of external braking resistors for dissipating braking energy.
• Ambient Temperature: -10 to +50°C (High Overload) and -10 to +40°C (Low Overload), according to Inverter Drive Supermarket.
• Dimensions:497 x 275 x 204 mm (H x W x D).
• Control Unit and BOP: Does not include a Control Unit or BOP (Basic Operator Panel).
• Applications: Designed for coupling the DC link of up to 10 Power Modules.
• Safety Features: Can be integrated with a Fail-safe Control Unit for safety-oriented applications.
• Communication: Supports various communication interfaces for seamless integration with automation system.
