Description
Omron ANALOG INPUT MODULE C200H-AD002
The Omron C200H-AD002 is a high-performance 8-point analog input module designed for the SYSMAC C200H and C200HS PLC series. It remains a staple in legacy industrial systems due to its reliability and built-in signal processing functions.
Technical Specifications:
|
Feature |
Details |
|
Input Points |
8 points (Channels) |
|
Resolution |
12-bit binary (1/4096) |
|
Input Ranges |
1–5V, 0–10V, -10 to +10V, 4–20mA |
|
Conversion Time |
2.5 ms per point (20 ms for all 8 points) |
|
Input Impedance |
1 MΩ (Voltage), 250 Ω (Current) |
|
Indicators |
RUN (Green): Normal operation Broken Wire (Red): Detected on 1–5V or 4–20mA ranges |
|
Built-in Functions |
Scaling, Mean Value, Peak Hold, Square Root |
Summery:
For current inputs (4–20mA), you must bridge the voltage input terminal and the current input terminal for that specific point. All inputs are non-isolated from each other but are isolated from the PLC internal circuitry. Omron recommends the CS1 series (using the CS1W-AD081-V1 module) or the modern NX/NJ series for EtherCAT-based architectures.
